Safe storage for your keys
EAGLE is the electronic storage that keeps all your keys safe.
There is one EAGLE for everyone
Our EAGLE are versatile electronic key storages that come in many sizes and security levels, all with the same intuitive functionalities and possibilities. Multiple cabinets can be combined to create one EAGLE assembly.
Fast access, easy handling, and secure storage
- Is key management a source of irritation for you and your coworkers?
- Are you dependent on fast key exchanges to make the schedule work?
- Are you compromising with security to make your operation run smoothly?
It doesn’t have to be like this, you can have it all! Make you life easier and your keys safer.
Get the all inclusive experience with a
EAGLE Kit
Life is to short spending it on searching for keys. Don’t waste your time and energy. All this is included for you. Get organized today!
- EAGLE Assembly
- AXSOR license
- System installation
- Paginated key rings
- Battery back-up
- Shipping
- Mounting and implementation
EAGLE vs competitors
It is easy to think that the choice of storage only comes down to the number of keys and the steel thickness. However, there is much more to it.
Have you thought about...
- ...how often the keys should be withdrawn
- ...what happens if you need to expand
- ...if you need to integrate your key systems
- ...how your insurance costs gets affected
We can give you the tools.
EAGLE models
Choose the assembly that suits your needs. From slimmer and more cost efficient EAGLE Light to certified thick encapsulations. Always in steel, always with emergency opening, and always fast to use.
EAGLE Light
EAGLE Light is a wall mounted assembly. One unit holds 96 positions. It is possible to expand the EAGLE Light to hold up to 576 positions, in 6 units built together. Each unit weighs 45 kg including the mounting plate.
EAGLE Light can be the most cost efficient option when security is not a big issue and the usage is not as frequent.
Match your needs
- Are your premises at an ok security level?
- Do you have a low usage frequency?
- Are the number of keys considerable?
Facts
Battery back-up | Yes |
| Emergency opening | Yes |
Steel thickness | 1.5 - 2 mm |
| Lock mechanism | Solenoid locking |
| Positions per unit | 96 |
| Maximum units | 6 |
| Weight | 45 kg |
| Measures in mm | h625 x w625 x d150 |
EAGLE Compact
EAGLE Compact is a wall mounted assembly. One unit holds 48 positions. It is possible to expand the EAGLE Compact to hold up to 288 positions, in 6 units built together. Each unit weighs 35 kg.
EAGLE Compact has the same base design as EAGLE Wall. The design allows the two models to be fitted together to form one EAGLE assembly. This model is most frequently used where the number of objects are modest.
Match your needs
- Are you in need of good security?
- Do you need to decentralize the key storage?
- Do you have a low number of keys?
Battery back-up | Yes |
| Emergency opening | Yes |
Steel thickness | 3 mm |
| Lock mechanism | Relieved lock bolt |
| Positions per unit | 48 |
| Maximum units | 6 |
| Weight | 35 kg |
| Measures in mm | h325 x w625 x d150 |
EAGLE Wall
EAGLE Wall is a wall mounted assembly. One unit holds 96 positions. It is possible to expand the EAGLE Wall to hold up to 576 positions, in 6 units built together.
EAGLE Wall has the same base design as EAGLE Compact. The design allows the two models to be fitted together to form one EAGLE assembly.
Match your needs
- Are you in need of good security?
- Do you use keys every day?
- Are the number of keys considerable?
Battery back-up | Yes |
| Emergency opening | Yes |
Steel thickness | 3 mm |
| Lock mechanism | Relieved lock bolt |
| Positions per unit | 96 |
| Maximum units | 6 |
| Weight | 72 kg |
| Measures in mm | h625 x w625 x d150 |
EAGLE Floor
EAGLE Floor is a standing assembly that can be mounted to the wall or floor. One unit holds 768 positions distributed on four extendable slide racks of 192 positions each.
It is not possible to expand an EAGLE Floor with more units, but it is possible to start with one to three slide racks and expand the number later. The assembly weighs 473 kg.
Match your needs
- Do you need to centralize the key handling?
- Are there a lot of individuals using the objects?
- Is the business large, with a lot of objects?
Battery back-up | Yes |
| Emergency opening | Yes |
Steel thickness | 4 mm |
| Lock mechanism | Relieved lock bolt |
| Positions per unit | 768 |
Slide racks | 4 |
| Weight | 473 kg |
| Measures in mm | h1910 x w830 x d500 |
EAGLE Safe SSF3492 certified
EAGLE Safe is a wall mounted assembly. One unit holds 96 positions for Objects and it is possible to expand the EAGLE Safe to hold up to 576 positions, in 6 units built together. Each unit weighs 104 kg.
EAGLE Safe is the model for smaller businesses that need certified storage according to SSF3492.
Match your needs
- Do you have high safety demands?
- Is the space limited in your office?
- Are the number of keys considerable?
Battery back-up | Yes |
| Emergency opening | Yes |
Steel thickness | 4 mm |
| Lock mechanism | Relieved lock bolt |
| Positions per unit | 96 |
| Maximum units | 6 |
| Weight | 104 kg |
| Measures in mm | h750 x w680 x d220 |
EAGLE Floor SSF3492 certified
EAGLE Floor SSF3492 is a certified floor standing assembly. It can be mounted to the wall or floor. One unit holds 768 positions distributed on four extendable slide racks of 192 positions each.
It is not possible to expand a certified EAGLE Floor with more units, but it is possible to start with one to three slide racks and expand the number later. The assembly weighs 473 kg.
Match your needs
- Do you need to access many keys quick?
- Do you need to fulfill insurance requirements?
- Will the business expand in a near future?
Battery back-up | Yes |
| Emergency opening | Yes |
Steel thickness | 4 mm |
| Lock mechanism | Relieved lock bolt |
| Positions per unit | 768 |
Slide racks | 4 |
| Weight | 473 kg |
| Measures in mm | h1910 x w830 x d500 |
EAGLE Grande SSF3492 certified
EAGLE Grande is the biggest unit when you have centralized key handling. One unit holds 1 152 positions distributed on six extendable slide racks of 192 positions each.
It is not possible to expand an EAGLE Grande with more units, but it is possible to start with one to five slide racks and expand the number later. The assembly weighs 620 kg.
Match your needs
- Do you have a lot of keys?
- Is there a space constraint?
- ....and high security demands?
Battery back-up | Yes |
| Emergency opening | Yes |
Steel thickness | 4 mm |
| Lock mechanism | Relieved lock bolt |
| Positions per unit | 1 152 |
Slide racks | 6 |
| Weight | 620 kg |
| Measures in mm | h1910 x w1350 x d550 |
The PAAM key management guide
In PAAMs key management guide we have gathered crucial information for you, what to consider, and how to approach a project to minimize risks and costs.
